Table 32
BACT12S TERMINAL LUG PART NUMBERS
Crimp Barrel
Size
(Wire Size
Range)
(AWG)
CAU Range Material
Tongue
Style
Stud Hole
Size
Boeing Standard
Minimum Maximum Body Plating
24-20 4 13 Cu Tin
Round 4 BACT12S12
Round 8 BACT12S13
Round 6 BACT12S8
Round 10 BACT12S9
Table 33
SUPPLIER PART NUMBERS FOR BOEING STANDARD BACT12S TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12S12 323985 Tyco/AMP
BACT12S13 323989 Tyco/AMP
BACT12S8 323986 Tyco/AMP
BACT12S9 323990 Tyco/AMP
Table 34
ROLLS-ROYCE TERMINAL LUG PART NUMBERS
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Part Number Supplier
Minimum Maximum
20-16 8 27 5 1909156 Rolls Royce
22-16 8 26 4 2509293 Rolls Royce
Table 35
ALTERNATIVE PART NUMBERS FOR ROLLS-ROYCE TERMINAL LUGS
Specified Terminal Lug Alternative Terminal Lug
Part Number Supplier Part Number Supplier
1909156 Rolls-Royce 150456 Tyco/AMP
2509293 Rolls-Royce 150471 Tyco/AMP
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
