Boeing 707 - Page 609

Table 12 WIRE INSULATION REMOVAL LENGTH FOR BACT13K TERMINAL LUGS (Continued)
Terminal Lug
Crimp Barrel Size
(Part Mark)
Removal Length
(inch)
Target Tolerance
BACT13K-4
2AL -4CU
0.75 ±0.03BACT13K-44
BACT13K-4A78 2AL 13-78
BACT13K-5 1/0AL - 2CU
0.82 ±0.03
BACT13K-5A78 1/0AL 13-78
BACT13K-6 2/0AL - 1/0CU
1.0 ±0.03
BACT13K-6A78 2/0AL 13-78
BACT13K-7 3/0AL - 2/0CU
1.0 ±0.03BACT13K-7A78 3/0AL 13-78
BACT13K-7W 3/0AL 2/0CU
BACT13K-8A78 4/0AL 13-78 1.0 ±0.03
Table 13
CRIMP TOOLS FOR BACT13K TERMINAL LUGS
Terminal Lug
Crimp Barrel Size
(Part Mark)
Crimp Tool
Power Unit Head Die Set
BACT13K-1 8AL - 10CU 69120
1752787-1
6800658422-1
69066
BACT13K-2 6AL - 8CU 69120
1752787-1
6800758422-1
69066
BACT13K-24 6AL - 8CU 69120
1752787-1
6800758422-1
69066
BACT13K-3 4AL - 6CU 69120
1752787-1
6800858422-1
69066
BACT13K-34 4AL - 6CU 69120
1752787-1
6800858422-1
69066
BACT13K-3A78 4AL 13-78 69120
1752787-1
6800858422-1
69066
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-14
Page 17
Feb 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
