Table 13 CRIMP TOOLS FOR BACT13K TERMINAL LUGS (Continued)
Terminal Lug
Crimp Barrel Size
(Part Mark)
Crimp Tool
Power Unit Head Die Set
BACT13K-4 2AL - 4CU 69120
1752787-1
6800958422-1
69066
BACT13K-44 2AL - 4CU 69120
1752787-1
6800958422-1
69066
BACT13K-4A78 2AL 13-78 69120
1752787-1
6800958422-1
69066
BACT13K-5 1/0AL - 2CU 69120
1752787-1
6801058422-1
69066
BACT13K-5A78 1/0AL 13-78 69120
1752787-1
6801058422-1
69066
BACT13K-6 2/0AL - 1/0CU 69120
1752787-1
68011-1
58422-1
69066 314964-1
BACT13K-6A78 2/0AL 13-78 69120
1752787-1
68011-1
58422-1
69066 314964-1
BACT13K-7 3/0AL - 2/0CU 69120
1752787-1
59877-1
58422-1
BACT13K-7A78 3/0AL 13-78 69120
1752787-1
59877-1
58422-1
BACT13K-7W 3/0AL - 2/0CU 69120
1752787-1
59877-1
58422-1
BACT13K-8A78 4/0AL 13-78 69120
1752787-1
1976443-1
58422-1
(1) Make a selection of insulation sleeve. Refer to Paragraph 2.F..
(2) Remove the necessary length of wire insulation.
Refer to:
• Table 12
• Subject 20-00-15 for the procedures to remove the insulation.
