NOTE: Refer to Paragraph 19. for the suppliers for the tools in Table 43.
Table 44
CRIMP TOOLS FOR NAS1387-() UNINSULATED BUTT SPLICES
Crimp
Barrel
Size
Crimp Tool
Basic Unit Holder Die
Part Number Supplier Part Number Supplier
Part
Number
Nest Supplier
22-18
1213804-1
(Battery powered)
Tyco/AMP 1213757-1 Tyco/AMP 49935 22-16 Tyco/AMP
46673 Tyco/AMP - - - - -
49900 Tyco/AMP - - - 22-18 -
49935 Tyco/AMP - - - 22-16 -
M22520/5-01 QPL - - Y641 22-18 -
16-14
1213804-1
(Battery powered)
Tyco/AMP 1213757-1 Tyco/AMP 49935 16-14 Tyco/AMP
46988 Tyco/AMP - - - - -
49900 Tyco/AMP - - - 16-14 -
49935 Tyco/AMP - - - 16-14 -
59294 Tyco/AMP - - - - -
M22520/5-01 QPL - - Y641 16-14 Daniels
12-10
1213804-1
(Battery powered)
Tyco/AMP 1213757-1 Tyco/AMP 49935 12-10 Tyco/AMP
49900 Tyco/AMP - - - 12-10 -
49935 Tyco/AMP - - - 12-10 -
59461 Tyco/AMP - - - - -
M22520/5-01 QPL - - Y641 12-10 Daniels
Table 45
CRIMP TOOLS FOR BACS52K() AND RAYCHEM D-609-() UNINSULATED BUTT SPLICES
Crimp Barrel Size
Crimp Tool
Basic Unit Supplier Nest
26-20
AD-1377 Tyco/Raychem 20-26
GMT232 Daniels 20-26
ST956C Boeing 20-26
ST956D Boeing 20-26
20-16
AD-1377 Tyco/Raychem 16-20
GMT232 Daniels 16-20
ST956C Boeing 16-20
ST956D Boeing 16-20
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 38
