WARNING
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE MAXIMUM
PERMITTED PRESSURE FOR THE CRIMP TOOL HEAD, AN INJURY TO
PERSONNEL CAN OCCUR.
CAUTION
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE MAXIMUM
PERMITTED PRESSURE FOR THE CRIMP TOOL HEAD, DAMAGE TO THE
CRIMP TOOL HEAD CAN OCCUR.
Table 43
CRIMP TOOLS FOR BACT12C() UNINSULATED BUTT SPLICES
Crimp
Barrel
Size
Crimp Tool
Basic Unit
Part Number
Holder Part
Number
Head Part
Number
Die Part
Number
Nest
Indenter Part
Number
Notes
12-10
1901235-1
(Battery
powered)
1804902-1 59461 - - - -
46447 - - - 12-10 - -
49900 - - - 12-10 - -
49935 - - - 12-10 - -
59461 - - - - - -
M8ND - - N10HT - - -
Y10MRF-5 - - - - - -
8
M8ND - - N8CT - - -
MR8-5 - - - - - -
Power Pump
-
1901343-1
(Battery
powered)
- 1901001-1 1901002-2 -
- 69069 - 47321 47322 -
- BDHD1 - DV8L-1 Y29PL -
- Y29B - DV8L-1 Y29PL -
- Y35BH - UV8L Y34PL -
Y8ND - - N8CT - - -
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 36
Feb 15/2021D6-54446
