Table 40 CRIMP TOOLS FOR INSULATED BUTT SPLICES (Continued)
Crimp
Barrel
Size
Crimp Tool
Basic Unit Holder Locator Die
Part Number Supplier Part Number Supplier
Part
Number
Nest Supplier
4
59974-1 Tyco/AMP - - 47822 - Tyco/AMP
69061 Tyco/AMP - - 47822 - Tyco/AMP
69091 Tyco/AMP - - 47822 - Tyco/AMP
2
59974-1 Tyco/AMP - - 47823 - Tyco/AMP
69061 Tyco/AMP - - 47823 - Tyco/AMP
69091 Tyco/AMP - - 47823 - Tyco/AMP
1/0
58422-1 Tyco/AMP - - 47824 - Tyco/AMP
69066 Tyco/AMP - - 47824 - Tyco/AMP
Table 41
CRIMP TOOL POWER PUMPS
Power Pump
Maximum Pressure
(psi)
Part Number Supplier
13597 Thomas & Betts 10,000
13600 Thomas & Betts 10,000
69120-() Tyco/AMP 8400
Y6NP Burndy 6000
Table 42
SATISFACTORY PRESSURES FOR THE OPERATION OF CRIMP TOOL HEADS
Crimp Tool Head
Pressure
(psi)
Part Number Supplier Minimum Maximum
13642M Thomas & Betts 9500 10000
69069 Tyco/AMP 8000 8400
BDHD1 Daniels 8500 9000
Y29B Burndy 5700 6000
Y35BH Burndy 9600 10500
NOTE: For the crimp tool heads shown in Table 42/SATISFACTORY PRESSURES FOR THE
OPERATION OF CRIMP TOOL HEADS, other power pumps that supply more than the
minimum specified pressure, and less than the maximum specified pressure shown in Table
42/SATISFACTORY PRESSURES FOR THE OPERATION OF CRIMP TOOL HEADS, can be
used.
