Table 39
CRIMP TOOLS FOR RAYCHEM D-609-0() PARALLEL SPLICES
Crimp Barrel Size
Crimp Tool
Basic Unit Part Number Nest Supplier
20-16
AD-1377 16-20 Tyco/Raychem
GMT232 16-20 Daniels
ST956C 16-20 Boeing
ST956D 16-20 Boeing
16-12
AD-1377 12-16 Tyco/Raychem
GMT232 12-16 Daniels
ST956C 12-16 Boeing
ST956D 12-16 Boeing
Table 40
CRIMP TOOLS FOR INSULATED BUTT SPLICES
Crimp
Barrel
Size
Crimp Tool
Basic Unit Holder Locator Die
Part Number Supplier Part Number Supplier
Part
Number
Nest Supplier
24-20
59275 Tyco/AMP - - - - -
69692-1 Tyco/AMP - - - - -
26-22
59275 Tyco/AMP - - - - -
69692 Tyco/AMP - - - - -
22-18
47386 Tyco/AMP - - - - -
59250 Tyco/AMP - - - Red -
69692-1 Tyco/AMP - - - - -
16-14
47387 Tyco/AMP - - - - -
59250 Tyco/AMP - - - Blue -
69693-1 Tyco/AMP - - - - -
12-10
1901235-1
(Battery powered)
Tyco/AMP 1804902-1 Tyco/AMP 59239 - Tyco/AMP
59239 Tyco/AMP - - - - -
8
59974-1 Tyco/AMP - - 47820 - Tyco/AMP
69061 Tyco/AMP - - 47820 - Tyco/AMP
69091 Tyco/AMP - - 47820 - Tyco/AMP
6
59974-1 Tyco/AMP - - 47821 - Tyco/AMP
69061 Tyco/AMP - - 47821 - Tyco/AMP
69091 Tyco/AMP - - 47821 - Tyco/AMP
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 34
Feb 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
