Table 43 CRIMP TOOLS FOR BACT12C() UNINSULATED BUTT SPLICES (Continued)
Crimp
Barrel
Size
Crimp Tool
Basic Unit
Part Number
Holder Part
Number
Head Part
Number
Die Part
Number
Nest
Indenter Part
Number
Notes
6 Power Pump
- 13642M ST2354-6 - - -
-
1901343-1
(Battery
powered)
- 1901000-1 1901002-2 -
- 69069 - 47321 47322 -
- BDHD1 - DV6L Y29PL -
- Y29B - DV6L Y29PL -
- Y35BH - UV6L Y34PLA -
4 Power Pump
-
1901343-1
(Battery
powered)
- 1901000-2 1901002-1
The 1901343-1
crimp tool with the
1901000-1 and
1901002-1 dies
are not allowed
with nickel coated
AWG 4 wire and a
BACT12C4 splice
- 69069 - 47321 47322 -
-
BDHD1
ST2354B-2 - - -
- - DV4L Y29PL -
- Y29B - DV4L Y29PL -
- Y35BH - UV4L Y34PLA -
2 Power Pump
- 13642M ST2354-1 - - -
-
1901343-1
(Battery
powered)
- 1901000-3 1901002-1 -
- 69069 - 47321 47322 -
- BDHD1 - DV2L Y29PL -
- Y29B - DV2L Y29PL -
- Y35BH - UV2L Y34PLA -
1/0 Power Pump
- 13642M 11738 - - -
- BDHD1 - DV25L Y29PL -
- Y29B - DV25L Y29PR -
- Y35BH - UV25L Y34PA -
2/0 Power Pump - Y35BH - UV26L Y34PA -
3/0 Power Pump - Y35BH - UV27L Y34PA -
4/0 Power Pump - Y35BH - UV28L Y34PA -
ASSEMBLY OF SPLICES
