Table 53 CRIMP TOOLS FOR SMALL BACT12AC TERMINAL LUGS (Continued)
Crimp
Barrel Size
Insulation
Color
Crimp Tool
Special
Instructions
Basic Unit Holder Head Die
22-18 Red
189721-1 356303-1 - 314270-1
For one AWG 24
wire, fold back
the conductor
314423-() - - 314270-1
314423-() - - 314270-2
314597-() - - 314270-1
314597-() - - 314270-2
46110 - - -
4B2-457540-6 - 687658-1 69872
59250 - - -
68075 - - 69872
69004 - - 47451
69005 - 47516 -
69118-() - - 45185-7
69365-() - - 47806-2
69875 - - 69872
16-14 Blue
189721-1 356303-1 - 314269-1
-
314423-() - - 314269-1
314423-() - - 314269-2
314597-() - - 314269-1
314597-() - - 314269-2
46110 - - -
565435-5 - 567200-2 69872
565435-5 - 567200-2 69873
59250 - - -
68075 - - 69873
69004 - - 47852
69005 - 47517 -
69118-() - - 45225-2
69118-() - - 45225-5
69365-() - - 47807-1
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 56
Feb 15/2016D6-54446
