Table 56 CRIMP TOOLS FOR BACT12AR TERMINAL LUGS (Continued)
Wire Size
Terminal Lug Crimp Tool
Crimp
Barrel
Size
Sleeve
Color
Band
Color
Basic Unit Holder Head Die
20 20 Red Red
189721-1 356303-1 - 314270-1
314423-() - -
314270-1
314270-2
314597-() - -
314270-1
314270-2
46110 - - -
4B2-457540-6 - 687658-1 69872
565435-5 - 567200-2 69872
59250 - - -
68075 - - 69872
69004 - - 47451
69005 - 47516 -
69118-() - - 45185-7
69365-() - - 47806-2
69692-1 - - -
69875 - - 69872
18 18 Red White
189721-1 356303-1 - 314270-1
314423-() - -
314270-1
314270-2
314597-() - -
314270-1
314270-2
46110 - - -
4B2-457540-6 - 687658-1 69872
565435-5 - 567200-2 69872
59250 - - -
68075 - - 69872
69004 - - 47451
69005 - 47516 -
69118-() - - 45185-7
69319-1 - - 47806-2
69365-() - - 47806-2
69875 - - 69872
