Table 1 ASSEMBLY PROCEDURES FOR SPECIFIED SPLICES (Continued)
Specified Splice Supplier Splice Assembly Configuration Reference
BACS52L2N2 Boeing
Sealed Butt Splice Kit (Nickel) - One to Two
Wires
Paragraph 7.G.
BACS52L2N4 Boeing
Sealed Butt Splice Kit - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kit - One to Three Wires Paragraph 7.I.
BACS52L2T2 Boeing Sealed Butt Splice Kit- One to Two Wires Paragraph 7.G.
BACS52L2T4 Boeing
Sealed Butt Splice Kit - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kit - One to Three Wires Paragraph 7.I.
BACS52L3N3 Boeing
Sealed Butt Splice Kit (Nickel) - One to Two
Wires
Paragraph 7.G.
BACS52L3N4 Boeing
Sealed Butt Splice Kit - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kit - One to Three Wires Paragraph 7.I.
BACS52L3T3 Boeing Sealed Butt Splice Kit- One to Two Wires Paragraph 7.G.
BACS52L3T4 Boeing
Sealed Butt Splice Kit - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kit - One to Three Wires Paragraph 7.I.
BACS52R Boeing Shielded Splice Kit, Tin Plated Subject 20-30-19
BACS52P Boeing Shielded Splice Kit, Nickel Plated Subject 20-30-20
BACT12C11 Boeing High Temperature Butt Splice Paragraph 8.A.
BACT12C15 Boeing High Temperature Butt Splice Paragraph 8.A.
BACT12C20 Boeing High Temperature Butt Splice Paragraph 8.A.
D-150-0251 Tyco/Raychem High Temperature Solder Sleeve Splice Kit Paragraph 16.A.
D-150-0272 Tyco/Raychem Solder Shield Splice Kit Paragraph 14.A.
D-436-36 Tyco/Raychem
Sealed Butt Splice Kits - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kits - One to Five Wires Paragraph 7.I.
D-436-37 Tyco/Raychem
Sealed Butt Splice Kits - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kits - One to Five Wires Paragraph 7.I.
D-436-38 Tyco/Raychem
Sealed Butt Splice Kits - One to Two Wires Paragraph 7.G.
Sealed Butt Splice Kits - One to Five Wires Paragraph 7.I.
D-436-58 Tyco/Raychem
Sealed Closed End Parallel Splice - All Wires
from the Same End of the Splice
Paragraph 5.C.
One Wire to Two Wires - Parallel Splice - Wires
from Both Ends of the Splice
Paragraph 7.F.
D-436-60 Tyco/Raychem Sealed Closed End Splice Kit Paragraph 5.B.
D-436-83 Tyco/Raychem Sealed Butt Splice Kit (Nickel) Paragraph 7.G.
D-436-83 Tyco
Sealed Closed End Parallel Splice - All Wires
from the Same End of the Splice
Paragraph 5.C.
One Wire to Two Wires - Parallel Splice - Wires
from Both Ends of the Splice
Paragraph 7.F.
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 8
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
