PARAGRAPH PAGE
14. SEALED SPLICE CONFIGURATIONS WITH SOLDER SHIELD SPLICE KITS FOR SHIELDED
WIRE AND SHIELDED CABLE (continued) 291
R. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit -
One Class 4 Shielded Cable to One Class 4 Shielded Cable 328
S. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit -
In-Line Resistor and Diode 330
15. SEALED SPLICE CONFIGURATIONS WITH SOLDER SLEEVE SHIELD SPLICES FOR
SHIELDED WIRE AND SHIELDED CABLE 332
A. Splice Assembly Configurations 332
B. Sealed Splice Configurations for Shielded Wire and Cable - Solder Sleeve Shield Splice
- One Shielded Wire to One Shielded Wire, Solder Sleeves, Tape, Sleeve 332
16. SEALED SPLICE CONFIGURATIONS WITH SOLDER SLEEVE SPLICE KITS FOR SHIELDED
WIRE AND SHIELDED CABLE FOR HIGH TEMPERATURE 335
A. Splice Assembly Configurations 335
B. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Solder
Sleeve Splice Kit - One Shielded Wire to One Shielded Wire 337
C. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Solder
Sleeve Splice Kit - One Shielded Wire to Two Shielded Wires 340
D. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Solder
Sleeve Splice Kit - One Class 2 Shielded Cable to One Class 2 Shielded Cable 343
E. Sealed Splice Configurations for Shielded Wire and Cable for High Temperature - Solder
Sleeve Splice Kit - One Class 2 Shielded Cable to Two Class 2 Shielded Cables 346
17. AMPHENOL 48 SERIES - DISCONNECTABLE REMOVABLE CONTACT SPLICE
350
A. Separation of the Plug and the Receptacle of the Splice-Connector 350
B. Contact Removal 350
C. Assembly of the Splice Connector 351
18. TYCO/AMP 6960() AND 2157() BREAKAWAY SPLICES 352
A. Assembly of Tyco/Amp 6960() and 2157() Breakaway splices 352
19. APPROVED TOOL SUPPLIERS
352
A. Splice Crimp Tools 352
B. Ferrule Crimp Tools 356
C. Shield-Kon Crimp Tools 362
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 6
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
