Boeing 707 - Page 704

Table 1 SPLICE KIT PART NUMBERS AND KIT GROUPS (Continued)
Shielded Splice Kit Part Number Splice Kit Group Supplier
D-150-0361 P2N1 Tyco
D-150-0362 P3N1 Tyco
D-150-0363 P1N2 Tyco
D-150-0364 P2N2 Tyco
D-150-0365 P2N3 Tyco
D-150-0366 P1N1 Tyco
D-150-0367 P2N1 Tyco
D-150-0368 P3N1 Tyco
D-150-0369 P2N2 Tyco
D-150-0370 P2N2 Tyco
D-150-0371 P3N2 Tyco
D-150-0372 P2N3 Tyco
D-150-0373 P3N3 Tyco
D-150-0374 P3N1 Tyco
D-150-0375 P3N2 Tyco
D-150-0376 P3N3 Tyco
D-150-0377 P3N2 Tyco
Table 2
WIRES ON EACH SIDE OF THE SPLICE ASSEMBLY AND THE APPLICABLE SPLICE KIT
Conductor
Splice
Quantity
Wiring on One Side of Splice
Assembly
Wiring on Other Side of Splice
Assembly
Splice Kit
1 BMS13-48T27C01G010
BMS13-48T27C01G010
D-150-0349
BMS13-60T52C01G016
1 BMS13-48T27C01G010 BMS13-60T52C01G012 D-150-0349
1 BMS13-48T27C01G010
BMS13-60T52C01G012
D-150-0349
BMS13-60T52C01G016
1 BMS13-48T27C01G010 BMS13-60T52C01G016 D-150-0349
1 BMS13-48T27C01G010
BMS13-60T52C01G016
D-150-0349
BMS13-60T52C01G022
1
BMS13-48T27C01G010
BMS13-48T27C01G010 D-150-0349
BMS13-60T52C01G016
1
BMS13-48T27C01G010 BMS13-60T52C01G012
D-150-0349
BMS13-60T52C01G016 BMS13-60T52C01G016
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 4
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
