Table 6 CABLE PREPARATION - STANDARD CONFIGURATIONS (Continued)
Splice Kit Group
Quantity of
Conductor
Splices
Wiring Configuration
Cable Preparation
One End of the Splice Other End of the Splice
P3N2 2
One Class 2 Cable One Class 2 Cable Paragraph 3.G.
One Class 2 Cable Two Class 1 Cables Paragraph 3.H.
One Class 2 Cable Two Class 2 Cables Paragraph 3.J.
One Class 2 Cable and
One Class 1 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.M.
Two Class 2 Cables Two Class 2 Cables Paragraph 3.K.
Two Class 2 Cables
Two Class 2 Cables,
Split Configuration
Paragraph 3.L.
P3N3 3
One Class 3 Cable One Class 3 Cable Paragraph 3.P.
One Class 3 Cable Two Class 3 Cables Paragraph 3.N.
Two Class 3 Cables Two Class 3 Cables Paragraph 3.O.
P3N3L 3
One Class 3 Cable One Class 3 Cable Paragraph 3.P.
One Class 3 Cable Two Class 3 Cables Paragraph 3.N.
Two Class 3 Cables Two Class 3 Cables Paragraph 3.O.
P4N1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
Table 7
CABLE PREPARATION - SPECIAL CONFIGURATIONS
Splice Kit Group Cable Configuration Special Instructions Cable Preparation
P1N2
1 Class 2 Cable
-
Paragraph 4.A.
Isolated Shields, AWG 22
Conductor
1 Class 2 Cable
-
Isolated Shields, AWG 20
Conductor
P2N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.B.
AWG 22 or AWG 24 Conductor
2 Class 1 Cables
-
AWG 22 or AWG 24 Conductor
P2N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.C.
AWG 22 or AWG 24 Conductor
1 Class 1 Cable
-
AWG 16, AWG 18, or AWG 20
Conductor
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 65
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
