Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit Group Cable Configuration Special Instructions Cable Preparation
P2N2
1 Class 2 Cable
Fold the conductors back
Paragraph 4.D.
AWG 22 Conductor
2 Class 1 Cables
Fold the conductors back
AWG 22 Conductor
P2N2
1 Class 2 Cable
Fold the conductors back
Paragraph 4.E.
AWG 22 Conductor
2 Class 2 Cables
-
AWG 22 Conductor
P2N2
1 Class 2 Cable
Fold the conductors back
Paragraph 4.F.
AWG 22 Conductor
1 Class 2 Cable
-
AWG 16, AWG 18, or AWG 20
Conductor
P2N2
1 Class 2 Cable
Fold the conductors back
Paragraph 4.G.
AWG 22 Conductor
1 Class 2 Cable
-1 Class 1 Cable
AWG 22 Conductor
P2N2
1 Class 2 Cable
-
Paragraph 4.A.
Isolated Shields, AWG 22
Conductor
1 Class 2 Cable
-
Isolated Shields, AWG 20
Conductor
P2N3
1 Class 3 Cable
Fold the conductors back
Paragraph 4.H.
AWG 22 Conductor
1 Class 2 Cable
Fold the conductors back1 Class 1 Cable
AWG 22 Conductor
P2N3
1 Class 3 Cable
Fold the conductors back
Paragraph 4.I.
AWG 22 Conductor
1 Class 3 Cable
-
AWG 16, AWG 18, or AWG 20
Conductor
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
