Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit Group Cable Configuration Special Instructions Cable Preparation
P3N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.B.
AWG 18 or AWG 20 Conductor
2 Class 1 Cables
-
AWG 18 or AWG 20 Conductor
P3N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.C.
AWG 18 or AWG 20 Conductor
1 Class 1 Cable
-
AWG 12 or AWG 14 Conductor
P3N1
1 Class 1 Cable AWG 22
Conductor
Fold the conductors back
Paragraph 4.N.
1 Class 1 Cable AWG 24
Conductor
1 Class 1 Cable AWG 14
Conductor
-
1 Class 1 Cable AWG 24
Conductor
P3N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.K.
AWG 18 Conductor
1 Class 1 Cable AWG 18
Conductor
-
1 Class 1 Cable AWG 22
Conductor
P3N1
1 Class 1 Cable
Fold the conductor back
Paragraph 4.L.
AWG 18 or AWG 20 Conductor
1 Class 3 Cable
-
AWG 20 Conductor
P3N1
2 Class 1 Cables
Fold the conductors back
Paragraph 4.N.
AWG 22 Conductor
1 Class 1 Cable AWG 14
Conductor
-
1 Class 1 Cable AWG 24
Conductor
P3N1
2 Class 1 Cables
Fold the conductors back
Paragraph 4.N.
AWG 22 Conductor
1 Class 1 Cable AWG 18
Conductor
-
1 Class 1 Cable AWG 20
Conductor
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 67
Jun 15/2021D6-54446
