Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit Group Cable Configuration Special Instructions Cable Preparation
P3N1
2 Class 1 Cables
Fold the conductors back
Paragraph 4.N.
AWG 22 Conductor
1 Class 1 Cable AWG 18
Conductor
-
1 Class 1 Cable AWG 22
Conductor
P3N2
1 Class 2 Cable
Fold the conductors back
Paragraph 4.F.
AWG 18 or AWG 20 Conductor
1 Class 2 Cable
-
AWG 12 or AWG 14 Conductor
P3N2
1 Class 2 Cable
-
Paragraph 4.O.
AWG 14 Conductor
1 Class 1 Cable AWG 20
Conductor
Fold the AWG 20 conductor
back
1 Class 1 Cable AWG 16
Conductor
P3N2
1 Class 2 Cable AWG 20
Conductor
Fold one of the Class 2 cable
conductors back
Paragraph 4.P.
1 Class 1 Cable AWG 20
Conductor
1 Class 2 Cable AWG 14
Conductor
-
1 Class 1 Cable AWG 20
Conductor
P3N3
1 Class 3 Cable
Fold the conductors back
Paragraph 4.I.
AWG 18 or AWG 20 Conductor
1 Class 3 Cable
-
AWG 12 Conductor
P3N3
One Class 3 Cable
Fold the conductors back
Paragraph 4.Q.
AWG 20 Conductor
One Class 3 Cable AWG 20
Conductor
Fold one of the Class 3 cable
conductors back
One Class 2 Cable AWG 20
Conductor
P4N1
1 Class 1 Cables
Fold the conductors back
Paragraph 4.B.
AWG 14 Conductor
2 Class 1 Cables
-
AWG 14 Conductor
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
