Table 60 CRIMP TOOLS FOR BACT12G AND BURNDY YBM SERIES FLAG TERMINAL LUGS
(Continued)
Crimp
Barrel Size
Crimp Tool
Basic Unit Type Head Adapter Nest Indenter
1/0
1213875-1 Battery Powered - - UV25B-1 Y29PA-1
BAT35 Battery Powered - Y35P3 UV25B-1 Y29PA-1
MY28
Large Adjustable
Hand Tool
- - - -
Power Pump -
BDHD1 - DV25BL-1
Y29PR
Y29B -
DV25BL
DV25BL-1
Y35BH Y35P3 UV25B-1
Y29PA
Y29PA-1
Y29BH Hydraulic Head - - DV25BL Y29PR
Y29NC Pneumatic Head - - DV25BL Y29PR
Y35 Hydraulic Hand - Y35P3 UV25B-1
Y29PA
Y29PA-1
Y6NP-5 - Y29B - DV25BL Y29PR
2/0
1213875-1 Battery Powered - - UV26B-1 Y29PA-1
BAT35 Battery Powered - Y35P3 UV26B-1 Y29PA-1
MY28
Large Adjustable
Hand Tool
- - - -
Power Pump -
BDHD1 - DV26BL Y29PR
Y29B - DV26BL Y29PR
Y35BH Y35P3 UV26B-1 Y29PA-1
Y35 Hydraulic Hand - Y35P3 UV26B-1 Y29PA-1
Table 61
GAGE PIN DIAMETER FOR THE CALIBRATION OF THE BURNDY MY28 CRIMP TOOL
Terminal Crimp Barrel Size
Gage Pin Diameter
(inch)
Target Tolerance
8 0.1360 0.0005
6 0.1360 0.0005
4 0.1960 0.0005
2 0.2950 0.0005
1/0 0.3906 0.0005
2/0 0.4375 0.0005
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 81
Feb 15/2016D6-54446
