Table 18
SLEEVE PART NUMBERS FOR BUTT SPLICES
Splice
Sleeve
Maximum Number of
Wires for the Seal of
the End
Number of Holes
in the Wire Seal
Part Number Color Stripe Supplier
BACT12C12
2 1 D-436-73 - Tyco/Raychem
1 1 DWP-125 - Tyco/Raychem
4 4 D-436-40 Yellow Tyco/Raychem
5 5 D-436-39 Red Tyco/Raychem
BACT12C4
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
BACT12C4NK
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
BACT12C6
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
BACT6NK
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
BACT12C8
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
BACT12C8NK
1 1 DWP-125 - Tyco/Raychem
5 3 D-436-41 Blue Tyco/Raychem
D-609-06
2 1 D-436-0096 Red Tyco/Raychem
5 3 D-436-95 Yellow Tyco/Raychem
D-609-07
2 1 D-436-0097 Blue Tyco/Raychem
2 1 D-436-73 - Tyco/Raychem
5 4 D-436-40 Yellow Tyco/Raychem
5 5 D-436-39 Red Tyco/Raychem
5 3 D-436-95 Yellow Tyco/Raychem
D-609-08
2 1 D-436-0098 Yellow Tyco/Raychem
2 1 D-436-73 - Tyco/Raychem
5 4 D-436-40 Yellow Tyco/Raychem
5 5 D-436-39 Red Tyco/Raychem
5 3 D-436-95 Yellow Tyco/Raychem
NAS1387-4
2 1 D-436-73 - Tyco/Raychem
5 4 D-436-40 Yellow Tyco/Raychem
5 5 D-436-39 Red Tyco/Raychem
