Table 19
PART NUMBERS OF SEALED SPLICE KITS FOR UNSHIELDED WIRE AND UNSHIELDED CABLE
Sleeve CAU Range
Part Number Supplier
Maximum Number of
Wires for the Seal of
the End
Number of Holes
in the Wire Seal
Minimum Maximum
2 1 3 15
M81824/1-1 QPL
BACS52L1N1 Boeing
BACS52L1T1 Boeing
D-436-36 TE/ Raychem
2 1 8 27
M81824/1-2 QPL
BACS52L2N2 Boeing
BACS52L2T2 Boeing
D-436-37 TE/ Raychem
2 1 19 67
M81824/1-3 QPL
BACS52L3N3 Boeing
BACS52L3T3 Boeing
D-436-38 TE/ Raychem
3 1
8 27
BACS52L2N4 Boeing
BACS52L2T4 Boeing
19 67
BACS52L3N4 Boeing
BACS52L3T4 Boeing
5 3
8 27 D-436-42 TE/ Raychem
19 67 D-436-43 TE/ Raychem
Table 20
COMPONENT PART NUMBERS OF SEALED SPLICE KITS
Splice Kit Component Part Number Crimp Barrel Size Color Stripe Supplier
M81824/1-1
Butt Splice BACS52K1 26-20 Red Boeing
Sleeve BACS13CM1 - Red Boeing
M81824/1-2
Butt Splice BACS52K2 20-16 Blue Boeing
Sleeve BACS13CM2 - Blue Boeing
M81824/1-3
Butt Splice BACS52K3 16-12 Yellow Boeing
Sleeve BACS13CM3 - Yellow Boeing
BACS52L1N1
Butt Splice BACS52K1N 26-20 Red/Red Boeing
Sleeve BACS13M1 - Red Boeing
BACS52L1T1
Butt Splice BACS52K2 20-16 Blue Boeing
Sleeve BACS13M1 - Blue Boeing
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
