Table 23 COMPONENT PART NUMBERS OF SEALED SPLICE KITS (Continued)
Splice Kit Component Quantity Part Number Supplier
D-150-0273
Butt Splice 2 NAS1387-6 QPL
Sleeve 2 D-436-73 Tyco/Raychem
Solder Shield Splice 1 D-155-0975 Tyco/Raychem
D-150-0285
Butt Splice 1 D-609-08 Tyco/Raychem
Sleeve 1 D-436-73 Tyco/Raychem
Solder Shield Splice 1 D-155-0550 Tyco/Raychem
Table 24
APPROVED SUPPLIERS OF COMPONENTS FOR SEALED SPLICE KITS
Component Supplier
NAS1387-6 Tyco/Raychem
Table 25
PART NUMBERS OF SEALED SPLICE KITS FOR HIGH TEMPERATURE SHIELDED WIRE AND
SHIELDED CABLE
CAU Range
Crimp Barrel Size Part Number Supplier
Minimum Maximum
8 27 20-16
D-150-0250 Tyco/Raychem
D-150-0252 Tyco/Raychem
19 67 16-12
D-150-0251 Tyco/Raychem
D-150-0253 Tyco/Raychem
Table 26
COMPONENT PART NUMBERS OF SEALED SPLICE KITS FOR HIGH TEMPERATURE
Splice Kit Component Quantity Part Number Special Features Supplier
D-150-0250
Butt Splice 1 D-609-10 - Tyco/Raychem
Splice Sleeve 1 ZDS-S-130 1.5 inch length Zeus
Shield 1 10494-9 - Tyco/Raychem
Solder Splice 2 D-108-11 - Tyco/Raychem
Outer Sleeve 1 ZDS-L-190 4.5 inch length Zeus
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 26
Feb 15/2021D6-54446
