Table 12
TERMINAL INSTALLATION TORQUE FOR RELAYS, CONTACTORS, GROUND FAULT INTERUPTERS
(GFI) AND TIME DELAY MODULES BY PART NUMBER
Relay, Contactor, GFI or Time Delay Module
Terminal Installation Torque
(inch-pounds)
Part Number Supplier Stud Size Minimum Maximum
10-61445-21 Boeing
6-32 5.5 7.5
10-32 22 24
10-61445-23 Boeing
6-32 5.5 7.5
1/4-28 46 56
10-61445-24 Boeing
6-32 5.5 7.5
1/4-28 46 56
530740-() Ducommun 6-32 5.5 7.5
530750-() Ducommun 6-32 5.5 7.5
60B00010-() Boeing 3/8-24 115 125
60B40021-() Boeing 3/8-24 115 125
9131-8506 Leach
6-32 5.5 7.5
10-32 22 24
D-25BD Hartman
6-32 5.5 7.5
1/4-28 46 56
D-31C Hartman
6-32 5.5 7.5
1/4-28 46 56
HDG-X2N-001 Leach
6-32 5.5 7.5
10-32 22 24
HT-C7N-060 Leach
6-32 5.5 7.5
10-32 22 24
HTDG-X7N-001 Leach
6-32 5.5 7.5
10-32 22 24
MS27751-( ) QPL
6-32 5.5 7.5
10-32 22 24
TD-1982-() Leach 6-32 5.5 7.5
ZCD-A1A-047 Leach
6-32 5.5 7.5
1/4-28 46 56
ZD-A5A-045 Leach
6-32 5.5 7.5
1/4-28 46 56
ELECTRICAL CONNECTION OF EQUIPMENT AND INSTALLATION OF TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-00
Page 27
Jun 15/2018D6-54446
