Table 120
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
B
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
C
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
D
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
J. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - Two Class
2 Shielded Cables to Three Class 2 Shielded Cables
Table 121
SPLICE KITS FOR TWO CLASS 2 SHIELDED CABLES TO THREE CLASS 2 SHIELDED CABLES
Jacket Maximum
O.D.
Shield Minimum
O.D.
Conductor CAU Range Solder Shield Splice Kit
Minimum Maximum Part Number Supplier
0.18 0.10 8 27 D-150-0175 Tyco/Raychem
0.22 0.14 19 67 D-150-0176 Tyco/Raychem
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 310
Jun 15/2021D6-54446
