Table 122
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
B
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
C
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
D
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
E
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 312
Jun 15/2021D6-54446
