Table 126
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
C3
D1 0.28
±0.02D2 0.77
D3 1.05
B C1
D1 0.28
±0.02D2 0.77
D3 1.05
C C1
D1 0.28
±0.02D2 1.92
D3 2.20
D C1
D1 0.28
±0.02D2 1.92
D3 2.20
M. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - One Class
3 Shielded Cable to One Class 3 Shielded Cable
Table 127
SPLICE KITS FOR ONE CLASS 3 SHIELDED CABLE TO ONE CLASS 3 SHIELDED CABLE
Jacket Maximum
O.D.
Shield Minimum
O.D.
Conductor CAU Range Solder Shield Splice Kit
Minimum Maximum Part Number Supplier
0.18 0.10 3 15 D-150-0179 Tyco/Raychem
0.22 0.14 8 27 D-150-0180 Tyco/Raychem
0.34 0.19 19 67 D-150-0181 Tyco/Raychem
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 316
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
