Table 132 CABLE TRIM DIMENSIONS (Continued)
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
D
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
C3
D1 0.28
±0.02D2 1.92
D3 2.20
P. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - Two Class
3 Shielded Cables to Two Class 3 Shielded Cables
Table 133
SPLICE KITS FOR TWO CLASS 3 SHIELDED CABLES TO TWO CLASS 3 SHIELDED CABLES
Jacket Maximum
O.D.
Shield Minimum
O.D.
Conductor CAU Range Solder Shield Splice Kit
Minimum Maximum Part Number Supplier
0.18 0.10 3 15 D-150-0179 Tyco/Raychem
0.22 0.14 8 27 D-150-0180 Tyco/Raychem
0.34 0.19 19 67 D-150-0181 Tyco/Raychem
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 323
Jun 15/2021D6-54446
