Table 1 AMP COPALUM TERMINAL PART NUMBERS (Continued)
Crimp Barrel
Stud
Size
Tongue Configuration Plating Part Number Supplier
Aluminum Wire
Size
(AWG)
Copper Wire
Size
(AWG)
2/0 1/0
5/16 Standard Tin 277152-3 Tyco/AMP
3/8
Short Tin 277152-2 Tyco/AMP
Long Tin 277152-4 Tyco/AMP
Two Stud Holes Tin 55839-1 Tyco/AMP
Long Tin 55944-1 Tyco/AMP
Flag Tin 55982-1 Tyco/AMP
1/2 Long Tin 277152-5 Tyco/AMP
3/0 2/0 3/8
Standard Tin 2325332-1 Tyco/AMP
Standard Tin 2327315-1 Tyco/AMP
Standard Tin 277153-1 Tyco/AMP
Two Stud Holes Tin 55840-1 Tyco/AMP
4/0 3/0 3/8 Standard Tin 55995-1 Tyco/AMP
NOTE: For power feeders terminated at the engine generator, high-temp terminal lugs must be used.
Refer to Subject 20-30-11 for BACT12M nickel plated high-temp terminal lugs.
Table 2
ALTERNATIVE COPALUM TERMINAL PART NUMBERS
Specified Terminal Alternative Terminal
Part Number Supplier Part Number Supplier
1-52521-0 Tyco/AMP 277152-4 Tyco/AMP
1-52521-1 Tyco/AMP 277152-5 Tyco/AMP
277028-2 Tyco/AMP 277153-1 Tyco/AMP
52516 Tyco/AMP 277147-1 Tyco/AMP
52517 Tyco/AMP 277148-5 Tyco/AMP
52517-1 Tyco/AMP 277148-1 Tyco/AMP
52517-2 Tyco/AMP 277148-2 Tyco/AMP
52517-3 Tyco/AMP 277148-3 Tyco/AMP
52517-4 Tyco/AMP 277148-4 Tyco/AMP
52518 Tyco/AMP 277149-1 Tyco/AMP
52518-1 Tyco/AMP 277149-2 Tyco/AMP
52518-2 Tyco/AMP 277149-3 Tyco/AMP
52518-3 Tyco/AMP 277149-4 Tyco/AMP
52518-4 Tyco/AMP 277149-5 Tyco/AMP
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
