C
CABLE A
CONDUCTOR
JACKET
CABLE B
CABLE C
SHIELD
INSULATION
A
C
B
1.00 ±0.02 INCH
C
B
C
A
1.00 ±0.02 INCH
C
B
C
A
1.00 ±0.02 INCH
2449464 S00061545708_V2
CABLE PREPARATION - 1 CABLE TO 2 CABLES, 2 CONDUCTORS
Figure 8
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 12
Feb 15/2022D6-54446
