PARAGRAPH PAGE
4. CABLE PREPARATION - SPECIAL CONFIGURATIONS (continued) 126
C. Kit Group P1N1, P2N1, P3N1 or P4N1 - One Class 1 Cable to One Class 1 Cable 132
D. Kit Group P1N2, P2N2 or P3N2 - One Class 2 Cable to Two Class 1 Cables 135
E. Kit Group P1N2, P2N2 or P3N2 - One Class 2 Cable to Two Class 2 Cables 138
F. Kit Groups P1N2, P2N2 or P3N2 - One Class 2 Cable to One Class 2 Cable 140
G. Kit Group P1N2, P2N2 or P3N2 - One Class 2 Cable to One Class 2 Cable and One
Class 1 Cable 143
H. Kit Group P2N3 or P3N3 - One Class 3 Cable to One Class 2 Cable and One Class 1
Cable 146
I. Kit Groups P2N3 or P3N3 - One Class 3 Cable to One Class 3 Cable 149
J. Kit Group P1N1, P2N1, P3N1 or P4N1 - One Class 1 Cable to Two Class 1 Cables 152
K. Kit Groups P1N1, P2N1, P3N1 or P4N1 - One Class 1 Cable to Two Class 1 Cables 155
L. Kit Group P1N1, P2N1, P3N1 or P4N1- One Class 1 Cable to One Class 3 Cable 158
M. Kit Group P1N2, P2N2 or P3N2 - One Class 2 Cable to One Class 2 Cable 160
N. Kit Group P1N1, P2N1, P3N1 or P4N1 - Two Class 1 Cables to Two Class 1 Cables 163
O. Kit Group P1N2, P2N2 or P3N2 - One Class 2 Cable to Two Class 1 Cables 166
P. Kit Group P3N2 - One Class 2 Cable and One Class 1 Cable to One Class 2 Cable and
One Class 1 Cable 169
Q. Kit Group P3N3 - One Class 3 Cable to One Class 3 Cable and One Class 2 Cable 172
5. CONDUCTOR SPLICE ASSEMBLY
174
A. Assembly of the Conductor Splice 174
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 2
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
