Table 5
BACT12AL GENERAL PURPOSE TERMINAL LUG PART NUMBERS
Crimp Barrel Size
(Wire Size)
(AWG)
CAU Range
Insulation Color Stud Hole Size Boeing Standard
Minimum Maximum
8 132 208 Red
8 BACT12AL2
10 BACT12AL3
1/4 BACT12AL4
5/16 BACT12AL5
3/8 BACT12AL6
6 209 331 Blue
8 BACT12AL9
10 BACT12AL10
1/4 BACT12AL11
5/16 BACT12AL12
3/8 BACT12AL13
4 332 526 Yellow
8 BACT12AL15
10 BACT12AL16
1/4 BACT12AL17
5/16 BACT12AL18
3/8 BACT12AL19
Table 6
SUPPLIER PART NUMBERS FOR BACT12AL TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12AL10
1-331460-0 Tyco/AMP
RE9261 Thomas & Betts
BACT12AL11
1-331460-1 Tyco/AMP
RE9711 Thomas & Betts
BACT12AL12
331461 Tyco/AMP
RE9721 Thomas & Betts
BACT12AL13
1-331461-0 Tyco/AMP
RE9731 Thomas & Betts
BACT12AL15
331456 Tyco/AMP
690-52622-3 Thomas & Betts
BACT12AL16
1-331456-0 Tyco/AMP
RF9261 Thomas & Betts
BACT12AL17
1-331456-1 Tyco/AMP
RF9711 Thomas & Betts
