Table 28 CONNECTIONS (Continued)
Wire Connection Wire Connected to
A2 Splice B2
A3 Splice B3
A4 Splice B4
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
NOTE: The shield material has fused ends that hold the ends of the strands of the shield
together.
(2) Put these components on Cable A In this sequence:
• The outer sleeve
• The small solder sleeve
• The shield material
• The large solder sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(3) Put a seal sleeve on the wire A1, wire A2, wire A3 and wire B4.
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 123
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
