Table 32
CONNECTIONS
Wire Connection Wire connected to
A Splice B
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
NOTE: The shield material has fused ends that hold the ends of the strands of the shield
together.
(2) If the splice kit has seal inserts and different size solder sleeves:
(a) Put these components on Cable A in this sequence:
• The outer sleeve
• A seal insert, if a build-up sleeve is not specified for the cable
• The small solder sleeve
• The shield material
• The large solder sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(b) Put the other seal insert on Cable B, if a build-up sleeve is not specified for the cable.
(3) If the splice kit has seal inserts and same size solder sleeves:
(a) Put these splice assembly components on Cable A in this sequence:
• The outer sleeve
• A seal insert, if a build-up sleeve is not specified for the cable
• A solder sleeve
• The shield material.
Make sure that the small end of the solder sleeve is put on the cable first.
(b) Put these splice assembly components on Cable B in this sequence:
• The other seal insert, if a build-up sleeve is not specified for the cable
• The other solder sleeve.
Make sure that the small end of the solder sleeve is put on the cable first.
(4) If the splice kit does not have seal inserts and has different size solder sleeves put these
components on Cable A in this sequence:
• The outer sleeve
• The small solder sleeve
• The shield material
• The large solder sleeve.
Make sure that:
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 133
Jun 15/2021D6-54446
