Table 10
BACT12AV SOLID NICKEL HIGH TEMPERATURE TERMINAL LUG PART NUMBERS
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Part Number
Minimum Maximum
22 - 18 7 24
6 BACT12AV011
8 BACT12AV012
10 BACT12AV013
1/4 BACT12AV014
16 - 14 15 51
6 BACT12AV021
8 BACT12AV022
10 BACT12AV023
1/4 BACT12AV024
12 - 10 43 138
6 BACT12AV031
8 BACT12AV032
10 BACT12AV033
1/4 BACT12AV034
Table 11
ALTERNATIVE TERMINAL LUG PART NUMBERS
Specified Terminal Lug Alternative Terminal Lug
Part Number Supplier Part Number Supplier
BACT12AV011 Boeing 321892 Tyco/AMP
BACT12AV012 Boeing 321896 Tyco/AMP
BACT12AV013 Boeing 321898 Tyco/AMP
BACT12AV014 Boeing 322320 Tyco/AMP
BACT12AV021 Boeing 322332 Tyco/AMP
BACT12AV022 Boeing 322337 Tyco/AMP
BACT12AV023 Boeing 322338 Tyco/AMP
BACT12AV024 Boeing 322341 Tyco/AMP
BACT12AV031 Boeing 323748 Tyco/AMP
BACT12AV032 Boeing 323749 Tyco/AMP
BACT12AV033 Boeing 323750 Tyco/AMP
BACT12AV034 Boeing 323751 Tyco/AMP
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 19
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
