Table 2 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52T3N3E
Conductor Splice BACS52K3N 3 Tyco
Seal Insert BACS13DL4 2 Tyco
Shield Material BACS13DK6 1 Tyco
Sleeve, Outer BACT63E8G 1 Tyco
Sleeve, Seal BACS13DJ3 3 Tyco
Solder Sleeve D-208-04 2 Tyco
BACS52T3T1B
Conductor Splice BACS52K3 1 Tyco
Shield Material BACS13DR1 1 Tyco
Sleeve, Outer BACT63E3E 1 Tyco
Sleeve, Seal BACS13DJ3 1 Tyco
Solder Sleeve D-208-06 2 Tyco
BACS52T3T1C
Conductor Splice BACS52K3 1 Tyco
Shield Material BACS13DR2 1 Tyco
Sleeve, Outer BACT63E4E 1 Tyco
Sleeve, Seal BACS13DJ3 1 Tyco
Solder Sleeve D-208-07 2 Tyco
BACS52T3T2C
Conductor Splice BACS52K3 2 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DR5 1 Tyco
Sleeve, Outer BACT63E4G 1 Tyco
Sleeve, Seal BACS13DJ3 2 Tyco
Solder Sleeve D-208-08 2 Tyco
BACS52T3T2D
Conductor Splice BACS52K3 2 Tyco
Seal Insert BACS13DL4 2 Tyco
Shield Material BACS13DR9 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ3 2 Tyco
Solder Sleeve D-208-08 1 Tyco
Solder Sleeve D-208-09 1 Tyco
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 11
Feb 15/2021D6-54446
