Refer to Figure 18.
Table 20
CONNECTIONS
Wire Connection Wire Connected to
A1 and B1 Splice C1 and D1
A2 Splice C2 and D2
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
NOTE: The shield material has fused ends that hold the ends of the strands of the shield
together.
(2) If the splice kit has seal inserts and different size solder sleeves:
(a) Put a seal insert on Cable A, if a build-up sleeve is not specified for the cable.
(b) Put these components on Cable A and Cable B in this sequence:
• The outer sleeve
• The small solder sleeve
• The shield material
• The large solder sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(c) Put the other seal insert on Cable C, if a build-up sleeve is not specified for the cable.
(d) If the seal insert O.D. is too small for the cable O.D., cut the seal insert along the axis and
wrap the seal insert around the cable.
(3) If the splice kit has seal inserts and the same size solder sleeves:
(a) Put a seal insert on Cable A, if a build-up sleeve is not specified for the cable.
(b) Put these splice assembly components on Cable A and Cable B in this sequence:
• The outer sleeve
• A solder sleeve
• The shield material.
Make sure that the small end of the solder sleeve is put on the cable first.
(c) Put the other seal insert on Cable C, if a build-up sleeve is not specified for the cable.
(d) If the seal insert O.D. is too small for the cable O.D., cut the seal insert along the axis and
wrap the seal insert around the cable.
(e) Put the other solder sleeve on Cables Cable C and Cable D
Make sure that the small end of the solder sleeve is put on the cables first.
(4) If the splice kit does not have seal inserts and has different size solder sleeves, put these
components on Cable A and Cable B in this sequence:
