Table 20
SOLID NICKEL HIGH TEMPERATURE TERMINAL LUG PART NUMBERS
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Part Number Supplier
Minimum Maximum
22 - 18 7 24
6 321892
Tyco/AMP
8
321893
321897
10
321894
321898
1/4 322320
16 - 14 15 51
6 322332
Tyco/AMP
8 322337
10 322338
1/4 322341
12 - 10 43 138
8 323749
Tyco/AMP10 323750
1/4 323751
Table 21
ALTERNATIVE TERMINAL LUG PART NUMBERS
Specified Terminal Lug Alternative Terminal Lug
Part Number Supplier Part Number Supplier
321892 Tyco/AMP BACT12AV11 Boeing
321896 Tyco/AMP BACT12AV12 Boeing
321898 Tyco/AMP BACT12AV13 Boeing
322320 Tyco/AMP BACT12AV14 Boeing
322332 Tyco/AMP BACT12AV21 Boeing
322337 Tyco/AMP BACT12AV22 Boeing
322338 Tyco/AMP BACT12AV23 Boeing
322341 Tyco/AMP BACT12AV24 Boeing
323748 Tyco/AMP BACT12AV31 Boeing
323749 Tyco/AMP BACT12AV32 Boeing
323750 Tyco/AMP BACT12AV33 Boeing
323751 Tyco/AMP BACT12AV34 Boeing
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 30
Oct 15/2015D6-54446
