Table 39
CONNECTIONS
Wire Connection Wire Connected to
A Splice B1, B2 and B3
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
(2) Put these splice assembly components on Cable A in this sequence:
• The outer sleeve
• A solder sleeve
• The shield material
Make sure that the small end of the solder sleeve is put on the cable first.
(3) Put the other solder sleeve on Cable B.
Make sure that the small end of the solder sleeve is put on the cable first.
(4) Put a seal sleeve on Wire A1.
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 97
Oct 15/2020D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
