Refer to Figure 38
Table 40
CONNECTIONS
Wire Connection Wire Connected to
A1 and B1 Splice C and D
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
NOTE: The shield material has fused ends that hold the ends of the strands of the shield
together.
(2) Put these splice assembly components on Cable A and Cable B in this sequence:
• The outer sleeve
• A solder sleeve
• The shield material
Make sure that the small end of the solder sleeve is put on the cables first.
(3) Put the other solder sleeve on Cable C and Cable D.
Make sure that the small end of the solder sleeve is put on the cables first.
(4) Put Wire A1 and Wire B1 together.
(5) Put a seal sleeve on Wire A1 and Wire B1 pair.
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 99
Oct 15/2020D6-54446
