CAUTION
HEAT MUST NOT BE APPLIED TO A HEAT SHRINKABLE SLEEVES THAT IS
INSTALLED OVER A SOLDER JOINT.
INSULATION OF THE WIRES IN THE INSULATION GRIP
Figure 8
CONFIGURATION OF THE INSULATION OF THE WIRES
Figure 9
ASSEMBLY OF TERMINALS AND SPLICES UNDER SPECIAL CONDITIONS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-22
Page 13
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
