Dell PowerConnect 5424 Command Line Interface Guide

Address Table Commands 105
User Guidelines
• The command is relevant only in port security max-addresses mode.
Example
In this example, port security mode is set to dynamic for Ethernet interface g7.
port security routed secure-address
The port security routed secure-address Interface Configuration mode command adds MAC-layer secure
addresses to a routed port. Use the no form of this command to delete the MAC addresses.
Syntax
• port security routed secure-address mac-address
• no port security routed secure-address mac-address
• mac-address — Specify a MAC address in the format of xx:xx:xx:xx:xx:xx.
Default Configuration
No addresses are defined.
Command Mode
Interface Configuration (Ethernet, port-channel). Cannot be configured for a range of interfaces
(range context).
User Guidelines
• The command enables adding secure MAC addresses to a routed ports in port security mode.
The
command is available when the port is a routed port and in port security mode. The address is
deleted if the port exits the security mode or is not a routed port.
Example
In this example, the MAC-layer address 66:66:66:66:66:66 is added to port g1.
Console(config)# interface ethernet g7
Console(config-if)# port security mode mac-addresses
Console (config)# interface ethernet g1
Console (config-if)# port security routed secure-address
66:66:66:66:66:66
5400_CLI.book Page 105 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
