Dell PowerConnect 5424 Command Line Interface Guide

106 Address Table Commands
show bridge address-table
The show bridge address-table Privileged EXEC mode command displays all entries in the bridge-
forwarding database.
Syntax
• show bridge address-table [ vlan vlan ] [ ethernet interface | port-channel port-channel-number ]
• vlan — Specific valid VLAN, such as VLAN 1.
• interface — A valid Ethernet port .
• port-channel-number — A valid port-channel number.
Default Configuration
This command has no default configuration.
Command Mode
Privileged EXEC mode.
User Guidelines
• Internal usage VLANs (VLANs that are automatically allocated on routed ports) would be presented in
the VLAN column by a port number and not by a VLAN ID.
Example
In this example, all classes of entries in the bridge-forwarding database are displayed.
Console# show bridge address-table
Aging time is 300 sec
vlan mac address port type
---- ----------- ---- ----
1 00:60:70:4C:73:FF g8 dynamic
1 00:60:70:8C:73:FF g7 dynamic
200 00:10:0D:48:37:FF g4 static
8 00:10:0D:48:37:FF g2 dynamic
5400_CLI.book Page 106 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
