Dell PowerConnect 5424 Command Line Interface Guide

ACL Commands 75
ACL Commands
ip access-list
The ip access-list Global Configuration mode command defines an IPv4 Access List and places the
device in IPv4 Access List Configuration mode. Use the no form of this command to remove the
Access List.
Syntax
• ip access-list access-list-name
• no ip access-list access-list-name
• access-list-name — Specifies the name of the IPv4 Access-List .
Default Configuration
No IPv4 Access List is defined.
Command Mode
Global Configuration mode.
User Guidelines
• IPv4 ACLs are defined by a unique name. An IPv4 ACL and MAC ACL cannot share the same
name.
Example
The following example shows how to define an IPv4 Access List called dell-access-1 and to place the
device in IPv4 Access List Configuration mode.
mac access-list
The mac access-list Global Configuration mode command enables the MAC-Access List
Configuration mode and creates Layer 2 ACLs. Use the no form of this command to delete an ACL.
Console(config)# ip access-list dell-access-1
Console(config-ip-al)#
5400_CLI.book Page 75 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
