Address Table Commands 97
bridge multicast address
The bridge multicast address Interface Configuration mode command registers MAC-layer Multicast
addresses to the bridge table, and adds static ports to the group. To unregister the MAC address, use the
no form of the bridge multicast address command.
Syntax
bridge multicast address
{
mac-multicast-address
|
ip-multicast-address
}
bridge multicast address
{
mac-multicast-address
|
ip-multicast-address
}
[
add
|
remove
]
{
ethernet
interface-list | port-channel port-channel-number-list
}
no bridge multicast address
{
mac-multicast-address
|
ip-multicast-address
}
add
— Adds ports to the group. If no option is specified, this is the default option.
remove
— Removes ports from the group.
mac-multicast-address
— MAC Multicast address in the format of xx:xx:xx:xx:xx:xx.
ip- multicast-address
— IP Multicast address.
interface-list
— Separate nonconsecutive Ethernet ports with a comma and no spaces; a hyphen is
used to designate a range of ports.
port-channel-number-list
— Separate nonconsecutive port-channels with a comma and no spaces;
a hyphen is used to designate a range of ports.
Default Configuration
No Multicast addresses are defined.
Command Mode
Interface Configuration (VLAN) mode.
User Guidelines
If the command is executed without
add
or
remove
, the command only registers the group in the
bridge database.
Static Multicast addresses can only be defined on static VLANs.
Examples
The following example registers the MAC address.
Console (config)# interface vlan 8
Console (config-if)# bridge multicast address 01:00:5e:02:02:03
5400_CLI.book Page 97 Wednesday, December 17, 2008 4:33 PM
