80 ACL Commands
User Guidelines
Use the
ip access-list
Global Configuration mode command to enable the IP-Access List
Configuration mode.
Before an Access Control Element (ACE) is added to an ACL, all packets are permitted. After an ACE
is added, an implied
deny-any-any
condition exists at the end of the list and those packets that do not
match the defined conditions are denied.
Example
The following example shows how to define a permit statement for an IP ACL.
permit (MAC)
The permit MAC-Access List Configuration mode command defines permit conditions of an MAC
ACL.
Syntax
permit
{
any
| {
host
source source-wildcard
}
any
| {
destination destination-wildcard
}} [
vlan
vlan-id
]
[
cos
cos cos-wildcard
] [
ethtype
eth-type
] [
inner-vlan
vlan-id
]
source
— Specifies the source MAC address of the packet.
source-wildcard
— Specifies wildcard bits to be applied to the source MAC address by placing 1s in
bit positions to be ignored.
any
— Specify a MAC address and mask. For example, to set 00:00:00:00:10:XX use the Mac
address 00:00:00:00:10:00 and mask 00:00:00:00:00:FF.
destination
— Specifies the MAC address of the host to which the packet is being sent.
destination-wildcard
— Specifies wildcard bits to be applied to the destination MAC address by
placing 1s in bit positions to be ignored.
vlan-id
— Specifies the ID of the packet vlan. (Range: 1 - 4094)
cos
— Specifies the Class of Service (CoS) for the packet. (Range: 0 - 7)
cos-wildcard
— Specifies wildcard bits to be applied to the CoS.
eth-type
— Specifies the Ethernet type of the packet in hexadecimal format. (Range: 0 - 05dd-ffff)
inner-vlan
vlad-id
— Specifies the inner vlan id of a double tagged packet.
Console(config)# ip access-list ip-acl1
Console(config-ip-al)# deny rsvp 192.1.1.1 0.0.0.255 any
5400_CLI.book Page 80 Wednesday, December 17, 2008 4:33 PM
