Dell PowerConnect 5424 Command Line Interface Guide

460 VLAN Commands
switchport mode
Use the switchport mode Interface Configuration command to configure the VLAN membership mode
of a port. Use the no form of this command to reset the mode to the appropriate default for the device.
Syntax
• switchport mode { access | trunk | general | customer }
• no switchport mode
• customer — The port is connected to customer equipment. Used when the switch is in a provider
network.
• access — Untagged layer 2 VLAN interface
• trunk — Trunking layer 2 VLAN interface
• general — Full 802.1q support VLAN interface
Default Configuration
Depends on the specific box.
Command Modes
Interface Configuration (Ethernet, port-channel)mode.
User Guidelines
• There are no user guidelines for this command.
Example
The following example configures the VLAN membership mode of a port. Use the no form of this
command to reset the mode to the appropriate default for the device.
switchport customer vlan
The switchport customer vlan Interface Configuration (Ethernet, port-channel) mode command sets
the port's VLAN when the interface is in customer mode. Use the no form of this command to restore
the default configuration.
Syntax
• switchport customer vlan vlan-id
• no switchport customer vlan
console# config
console(config)# interface ethernet g1
console(config-if)# switchport mode customer
5400_CLI.book Page 460 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
