Page #461 background imageLoading...
Page #461 background image
VLAN Commands 461
Default Configuration
No VLAN is configured.
Command Modes
Interface Configuration (Ethernet, port-channel) mode.
User Guidelines
There are no user guidelines for this command.
Example
The following example sets the port's VLAN when the interface is in customer mode.
map protocol protocols-group
The map protocol protocols-group VLAN Configuration mode command maps a protocol to a protocol
group. Protocol groups are used for protocol-based VLAN assignment. Use the no form of this command
to delete a protocol from a group.
Syntax
map protocol
protocol
[
encapsulation
]
protocols-group
group
no map protocol
protocol
encapsulation
protocol
— The protocol is a 16 or 40 bits protocol number or one of the following names; ip, arp,
ipv6, and ipx. The protocol number is in Hex format. (Range: 0600 - FFFF)
encapsulation
— One of the following values:
ethernet
,
rfc1042
or
llcOther
. If no option is
indicated the default is
ethernet
.
group
— Protocol group number. (Range: 1 - 2147483647)
Default Configuration
This command has no default configuration.
Command Mode
VLAN Configuration mode.
User Guidelines
There are no user guidelines for this command.
Console(config)#
switchport customer vlan
vlan-id
5400_CLI.book Page 461 Wednesday, December 17, 2008 4:33 PM
