Dell PowerConnect 5424 Command Line Interface Guide

IP Addressing Commands 209
arp
The arp Global Configuration mode command adds a permanent entry in the Address Resolution
Protocol (ARP) cache. Use the no form of this command to remove an entry from the ARP cache.
Syntax
• arp i p_addr hw_addr { ethernet i nterface-number | vlan vlan-id | port-channel number }
• no arp i p_addr { ethernet i nterface-number | vlan vlan-id | port-channel number }
• ip_addr — IP address or IP alias to map to the specified MAC address.
• hw_addr — MAC address to map to the specified IP address or IP alias.
• ethernet interface-number — Ethernet port number.
• vlan vlan-id — VLAN number .
• port-channel number — Port-channel number.
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode.
User Guidelines
• The software uses ARP cache entries to translate 32-bit IP addresses into 48-bit hardware addresses.
Because most hosts support dynamic resolution, static ARP cache entries do not need to be specified.
Console# show ip interface
Gateway IP Address Type Activity Status
--------------------- ----------- ---------------
10.7.1.1 Static Active
IP address Interface Type
------------------- ------------ ------------
10.7.1.192/24 VLAN 1 Static
10.7.2.192/24 VLAN 2 DHCP
5400_CLI.book Page 209 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
