Dell PowerConnect 5424 Command Line Interface Guide

344 SNMP Commands
Example
The following example displays the configuration of views use the show snmp views Privileged EXEC
command.
show snmp filters
The show snmp filters Privileged EXEC mode command displays the configuration of filters.
Syntax
• show snmp filters [ filtername ]
• filternam — The name of the view . Range: Up to 30 character
Console # show snmp groups
Name Security Views
Model Level Context Read Write Notify
user-group V3 priv - Default -
managers-group V3 priv - Default Default -
managers-group V3 priv - Default -
Console # show snmp groups user-group
Name: user-group
Security Model: V3
Security Level: priv
Security Context: -
Read View: Default
Write View: ""
Notify View: ""
5400_CLI.book Page 344 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
