Dell PowerConnect 5424 Command Line Interface Guide

QoS Commands 293
Example
The following example sets queue 8, 7 to be expedite queues.
traffic-shape
The traffic-shape Interface Configuration (Ethernet, Port-Channel) mode command sets the shaper on
an egress port. Use the no form of this command to disable the shaper.
Syntax
• traffic-shape committed-rate [committed –burst]
• no traffic-shape
• committed-rate — Specifies the average traffic rate (CIR) in kbps. (Range for GE ports is 64 -
1,000,000 kbps)
• committed-burst — Specifies the excess burst size (CBS) in bytes. (Range for GE ports is 4KB –
16MB)
Default Configuration
The default configuration is disabled.
Command Mode
Interface Configuration (Ethernet, Port-Channel) mode.
User Guidelines
• There are no user guidelines for this command.
Example
The following example sets the shaper on Ethernet port 1/g15 to 64kpbs committed rate.
rate-limit (Ethernet)
The rate-limit Interface Configuration (Ethernet) mode command limits the rate of the incoming
traffic. Use the no form of this command to disable the rate limit.
Console (config)# priority-queue out num-of-queues 2
console(config)# interface ethernet g/g15
console(config-if) traffic-shape 64
5400_CLI.book Page 293 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
