Dell PowerConnect 5424 Command Line Interface Guide

802.1x Commands 507
Syntax
• dot1x single-host-violation { forward | discard | discard-shutdown } [ trap seconds ]
• no port dot1x single-host-violation
• forward — Forward frames with source addresses not the supplicant address, but do not learn the
address.
• discard — Discard frames with source addresses not the supplicant address.
• discard-shutdown — Discard frames with source addresses not the supplicant address. The port is
also shutdown.
• trap seconds — Send SNMP traps, and specifies the minimum time between consecutive traps.
(Range:
1 - 1000000 )
Default Configuration
Discard frames with source addresses not the supplicant address. No traps.
Command Mode
Interface Configuration (Ethernet) mode.
User Guidelines
• The command is relevant when Multiple hosts is disabled and the user has been successfully
authenticated.
Examples
The following example uses the forward action to forward frames with source addresses.
dot1x guest-vlan
The dot1x guest-vlan Interface Configuration mode command defines a Guest VLAN. Use the no form
of this command to return to default.
Syntax
• dot1x guest-vlan
• no dot1x guest-vlan
Default Configuration
No VLAN is defined as a Guest VLAN.
console config-if(Config-VLAN)# dot1x single-host-violation
forward trap 100
5400_CLI.book Page 507 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
